RFID Gives Voice to Nonverbal Children

Thanks to its built-in RFID interrogator, the Logan ProxTalker can identify words that autistic children want to say—and utter them on their behalf.
Published: May 19, 2009

When nonverbal students at New York Public Schools District 75 in Queens first got their hands on the Logan ProxTalker, developed by Connecticut start-up company ProxTalker.com, they began communicating. According to Karen Gorman, the district’s assistive technology evaluation coordinator, it all started with a simple “good morning.” But when the children—who are not able to speak due to multiple disabilities, such as autism—began working with the device given to them by their teacher, they were soon putting together entire sentences.

The Logan ProxTalker, approximately the size of a laptop computer, was designed by Glen Dobbs, ProxTalker.com’s president, and Kevin Miller, the company’s VP. The device employs radio frequency identification to help a child instruct the machine what to say, and comes with an RFID interrogator and tags—known as Sound Tags—each with a word or phrase, and usually a corresponding image, printed on the front. When a child moves a tag over the machine, it announces the word that tag represents.


Logan Dobbs, the autistic son of ProxTalker.com’s president, uses the device named in his honor.

Dobbs’ 11-year-old son, Logan, is autistic and does not speak. Like other children with speech impairments, he used the Picture Exchange Communication System (PECS), whereby a child can select tiles with images printed on the front, place them in a specific order to express what he or she wishes to say, and then show the arrangement to a teacher or parent. The problem with that system, Dobbs says, is that it does not work when a caretaker or other adult has not been trained to understand it. Another drawback with PECS, he says, is that it doesn’t help children speak out or be heard when they need to say something—from the backseat of a car, for instance.

The Logan ProxTalker gives a voice to a child’s chosen words. Each device comes with a row of five pads on which a Sound Tag can be placed, enabling the user to string words together in order to construct a sentence. Each pad has a coil antenna connected to a single Texas Instruments RFID reader chip in the device. The Sound Tags, manufactured by Vanguard ID Systems, contain a 13.56 MHz tag complying with the ISO 15693 standard. When a tag is moved near one of the pads, the Logan ProxTalker reads the corresponding word out loud.

“We dialed the read range down so that it would have to be very near, or on the button, to be read,” Dobbs says. Although the tag must be close, it need not be exactly on the pad for the tag’s ID number to be captured. That makes it a better technological choice than bar codes or LEDs for an optical system, he notes, both of which would have required a much closer and tighter positioning of the tag in order to be properly read.
The Logan ProxTalker can enunciate up to 10,000 different words, and includes a feature enabling teachers and other operators to add a new word by placing a Sound Tag on a reader, inputting a command to record, and speaking the new word that the Sound Tag will represent.

ProxTalker.com has loaned several of the devices to New York Public Schools District 75 for testing, Gorman says. In one classroom in Queens, a half-dozen children between the ages of five and eight have been sharing four of the machines for the past two months, along with 100 Sound Tags for each unit, though she says the potential to improve communication for the children displayed itself on the first day they began using them. “It took off so much better than we imagined in the first couple of minutes,” she states. The students began with one word, then started putting multiple words together and communicating with each other. “That is our goal—for nonverbal kids to communicate with each other.”


Glen Dobbs, ProxTalker.com’s president

The system improves on the traditional PECS systems, Gorman says, because it allows for a much larger volume of words from which to choose, and because the voice makes communication quicker and easier. It offers a good interim tool, she adds, for children who would like to communicate more directly than PECS allows, before they grapple with a much more sophisticated computer-based system intended for higher-functioning nonverbal children and adults. According to Gorman, the district will continue testing the system during the next school year, before determining whether to purchase the machines for the children in Queens, or for those in other schools in the district.

Other customers of the Logan ProxTalker, Dobbs says, are predominantly speech, behavioral, psychological and occupational therapists, schools, special educators, families, pediatricians and hospitals. The device costs approximately $2,400, and comes with 80 preprogrammed Sound Tags and 20 blanks with which to record other words. If desired, a customer can purchase additional tags.

“It’s great to be in an industry where the product you’re making is changing people’s lives for the better,” Dobbs says.
